PV Wire 10 AWG 2000 Volts 500 Feet Black - 2KV-UL4703

Single conductor photovoltaic wire rated for interconnection wiring of grounded and ungrounded photovoltaic power systems. Approved for Direct Burial rated for a maximum continuous operating temperature between -40°C and 90°C in wet and 105°C in dry conditions.

Applicable Standards and Tests:

ASTM B-1, B-3, B33 and B-8, CSA C22.2 No. 271-11, ICEA S-95- 658/NEMA WC70, ICEA S-66-524/NEMA WC7, NEC NFPA 70, NEC 310, NEC Section 690.31, UL 44, UL 66, UL 83, UL 854, UL 1581, UL 4703 All products are spark tested at 7500 VAC unless otherwise specified.

Conductors:

The single conductors stranded annealed copper

Insulation:

Concentrically applied XLP (crosslinked polyethylene) insulation, rated at 2000V. Sunlight Resistant, FV-1 flame retardant, Oil and Gasoline Resistant Cat I.
